High load capacity configurable rack
This is a for sheets metal transport with maximum
dimensions of 4 x 2 meters
It has the feature that it can be configured with
various different maximum openings
TECHICAL DATA
PAYLOAD | 3300 KG |
|---|---|
MAX FORKLIFTING | 5000 KG |
STACKING | 16000 KG |
EMPTY WEIGHT | 700 KG |
CAPACITY | 4000 X 2000 X 100 mm |
MAX SIZE | 4110 X 2230 X 710 mm |
MIN SIZE | 2280 X 2230 X 710 mm |
FORKS DISTANCE | 1200 mm |
It can be lifted with forklift or cranes with four lifting points,
transported on a truck or used for warehouse storage
It is particularly suitable for containing shaped metal sheet kits for bending operations
The load tacks can be positioned according to the load size
Sheet metal can be loaded and removed with a forklift or overhead crane
A special plastic material foils with 70 shore hardness
is applied to all surfaces in contact with the load
FEA stress analysis
was performed considering the various conditions of use and involved accelerations
