High load capacity configurable rack
This is for crane assembly transport with maximum containment of
dimensions 356 x 96 x 110 cm
It has the feature that it can be configured with
width-adjustable clamping of assembled groups
TECHICAL DATA
PAYLOAD | 2600 KG |
|---|---|
MAX FORKLIFTING | 5000 KG |
TRANSPORT | 6000 KG |
STACKING | 10000 KG |
EMPTY WEIGHT | 460 KG |
CAPACITY | 3560 X 960 X 1100 mm |
MAX SIZE | 3800 X 1180 X 1305 mm |
MIN SIZE | 3800 X 1180 X 570 mm |
FORKS DISTANCE | 1100 mm |
It can be lifted with forklift or cranes with four lifting points,
transported on a truck or used for warehouse storage
It is particularly suitable for containing complete already painted assembled groups
The four corner stops for containment can be positioned according to the load size
Assembled groups can be loaded and removed with a forklift or overhead crane
A special plastic material foils with 70 shore hardness
is applied to all surfaces in contact with the load
Stacking with load takes place via four pluggable support pillars,
which can be folded down for empty storage
FEA stress analysis
was performed considering the various conditions of use and involved accelerations
